Specifications
|
|
Platform
|
Intel® Ultra Mobile platform 2008
– I Intel® Centrino® Atom™ processor Z530 (1.6GHz, 512 L2 Cache, 200Mhz)
– Intel® System Controller Hub
|
|
Operating System
|
Genuine Windows Vista® Home Premium
( or Genuine Windows Vista® Business)
|
|
Display
|
5.6-inch SuperFine WXGA, 1280×800 pixels, Passive Touch display
|
|
Memory
|
1 GB DDR2 533MHz
|
|
Hard Disk
|
60GB
|
|
Bluetooth®
|
v2.1 + EDR
|
|
Battery
|
Up to 3.5hrs 1 (2-cell Lithium-ion 7.2V 2900mAh
|
|
Weight
|
Approx. 610g
|
|
|
Detailed Specifications
|
|
Hard Disk Drive
|
60GB/100GB HDD: 1.8" PATA Ultra DMA 100 (4200rpm), 2 plates, S.M.A.R.T support, Two Partitions – 50/502
|
|
Graphics
|
Integrated Intel® Graphics with 3D Accelerator
|
|
Audio
|
Realtek HD Audio Codec ALC269 with built in speaker and digital microphone
|
|
Communication
|
Bluetooth® v2.1, Realtek 8101L Fast Ethernet, Atheros® XSPAN™ 802.11n3 with dual Antenna, 1.3Mega Pixel Camera, GPS4
|
|
User Interface
|
Keyboard 68 keys, 15mm pitch, 1.3mm key stroke
Glide Point with two buttons (left & right)
Touch Screen Panel with Stylus Pen
4 LEDs Indicator (Power-LED, DC-IN/Charge-LED, BatteryStatus-LED, HDDaccess-LED)
|
|
Card Slots
|
1 x Type I/II CF Card slot
1 x Secure Digital (SD) Card Reader
|
|
Connector Interface
|
USB 2.0 x 1, Audio-in, Audio-out, Power Adapter DC-in, VGA (external display) and RJ45 (LAN) via bundled LAN/ VGA adapter connector
|
|
Quick Launch Panel
|
Two programmable application buttons, two programmable up/down key buttons, one rotation button, one CtrlAlt+Del button and one FnKey button
|
|
Security5
|
User and supervisor BIOS password, Boot Sector Write Prevention, Fingerprint Sensor, SMART HDD, Anti-theft Lock Slot
|
|
Dimensions (WxDxH)
|
Approx. 171 x 135 x 26.5 — 33.0 mm
|
|
|
Bundled Accessories
|
|
AC Adapter
|
Input: AC100-240V, Output: DC16V,2.5A (40W)
|
|
Bundled Software
|
Microsoft® Origami™ Experience 2.0 Pack( on Genuine Windows Vista® Home Premium only), Acronis True Image, Softex OmniPass, ArcSoft Camera Capture, Adobe Acrobat Reader, Sun Microsystems Java Runtime, Fujitsu UpdateNavi6, Fujitsu Hardware Diagnostic Tool, Fujitsu Display Manager, Roxio Easy Media Creator, Microsoft Office Professional 2007 60-day Convertible Trial 7
|
|
Other Softwares
|
1 year Full Licensed Norman Virus Control
|
|
VGA / LAN Adapter8
|
External adaptor for connection to RJ45 (LAN), VGA (external display)
|
|
Carrying Case8
|
Portable Slip Case bundled
|
|
|
Optional Accessories
|
|
Port Replicator
|
Connector Interface:
USB 2.0 x 4, VGA (external display), RJ45 (LAN), Power Adapter DC-in
Dimension: 190 (w)x 110(d)x 159 (h) mm
Weight: 330g
|
|
Extended Battery
|
Up to 7.5 hrs1 (4-cell Lithium-ion 7.2V 5800mAh)
|
|
|
|
